NeoEdge NG4500-CB01 Carrier Board for Jetson Orin Nano/NX
$249.00
The NeoEdge NG4500-CB01 is a board-only carrier for Jetson Orin Nano 4GB/8GB and Orin NX 8GB/16GB. It provides dual Gigabit Ethernet, USB, industrial I/O, M.2 expansion and dual 4-lane MIPI CSI inputs for custom edge AI systems. Jetson module, cooling, storage, power and peripherals are sold separately. For an enclosure-ready system, choose the NG4500 Jetson Orin AI box.
- Supports Jetson Orin Nano 4GB/8GB and Orin NX 8GB/16GB modules through a 260-pin SO-DIMM socket.
- Connects cameras, networks and industrial equipment through dual Gigabit Ethernet, USB, HDMI, RS232, RS485, CAN and isolated DI/DO.
- Adds two M.2 Key M storage paths, M.2 Key B cellular expansion, M.2 Key E Wi-Fi/Bluetooth expansion and a Nano SIM slot.
- Provides two 4-lane MIPI CSI camera inputs plus a 14-pin expansion connector for GPIO, I2C, SPI and UART.
- Accepts 12 to 36 V DC input, with module-specific power settings and a qualified thermal solution required before operation.
This SKU contains the NG4500-CB01 carrier board only. It does not include a Jetson module, heat sink, fan, SSD, power adapter, enclosure, antennas, camera, wireless module or connection cable.
SKU: 73.002.000005
Category: Edge AI Boxes
Pay with Ease
- Customization Service
- OEM / ODM Support
- Bulk Order Pricing
- Worldwide Express Delivery
- Warranty Coverage & Lifetime Support
Contact us at sales@camthink.ai
Product Overview
The NeoEdge NG4500-CB01 is the carrier board used by the NG4500 platform. It gives developers direct access to Jetson Orin Nano and Orin NX compute modules while adding the networking, storage, camera and industrial interfaces needed for machine vision, robotics, automation and AIoT gateway prototypes. Compute performance comes from the Jetson module you install, so the board can be paired with a lower-power Orin Nano or a higher-memory Orin NX configuration.
The board has two Gigabit Ethernet ports, four USB 3.1 Type-A ports, one USB 3.2 Type-C port, HDMI, audio, RS232, RS485, CAN, four isolated digital inputs and four isolated digital outputs. Two M.2 Key M slots support system and secondary storage. Separate Key B and Key E slots provide cellular and Wi-Fi/Bluetooth expansion, while two 4-lane MIPI CSI connectors support camera development. See the NG4500-CB01 development guide for the full board workflow.
Choose this board when you need open access for firmware work, driver integration, custom I/O or your own enclosure. If your project needs a tested metal enclosure, installed Jetson module, power accessories and a faster path to field deployment, use the assembled NeoEdge NG4500 edge AI box instead.
Product Key Features
Jetson Orin module support
The 260-pin SO-DIMM socket accepts Jetson Orin Nano 4GB/8GB and Orin NX 8GB/16GB modules. Select the module according to model size, memory demand, power budget and thermal design. CPU, GPU, Tensor core count and TOPS are module specifications, not carrier-board specifications.
Networking and industrial I/O
Dual 100/1000 Mbps Ethernet ports support separate device and upstream network paths. RS232, RS485, CAN, four isolated DI channels and four isolated DO channels let the board connect to sensors, controllers, alarms and industrial equipment without relying only on USB.
Storage and wireless expansion
The board provides two M.2 Key M 2280 slots, one with a 4-lane PCIe path and one with a 1-lane PCIe path. Use the 4-lane slot for the primary NVMe system drive. M.2 Key B supports cellular expansion, and M.2 Key E 2230 supports Wi-Fi/Bluetooth modules.
Camera, display and audio paths
Two 4-lane MIPI CSI connectors support camera integration. HDMI output, a 3.5 mm audio jack and additional audio headers support local display, microphone, line-level and speaker integration. Camera and audio hardware may require driver or device-tree work.
Board-level expansion and recovery
A 14-pin FFC connector exposes GPIO, I2C, SPI, UART and 3.3 V power for custom peripherals. The board also includes debug, recovery, reset, power-button, fan and RTC connections for development and system integration. Use the published interface and module configuration guide when assigning pins or enabling interfaces.
Compatible Add-ons and Complete Systems
| Product | Use it when | Store link |
|---|---|---|
| Jetson Orin active heat sink | You need the documented active cooling path for an Orin Nano or Orin NX module. | Active heat sink for Jetson Orin |
| M.2 2280 NVMe SSD | You need a primary system drive or secondary local storage. The 4-lane Key M slot is recommended for the system SSD. | M.2 2280 NVMe SSD, 256GB / 512GB / 1TB |
| Dual-band Wi-Fi 5 and Bluetooth 5.0 module | You need local wireless networking and Bluetooth through the M.2 Key E slot. | M.2 Key E Wi-Fi and Bluetooth module |
| Quectel 4G module | You need LTE connectivity through the M.2 Key B slot. Antennas, SIM and carrier service are separate requirements. | Quectel EM05 4G module |
| Quectel 5G module | You need 5G connectivity through the M.2 Key B slot. Confirm regional bands before ordering. | Quectel RM520N 5G module |
| Raspberry Pi Camera Module V2 | You want the documented IMX219 reference camera for CSI development. Check cable orientation and the current driver guide. | IMX219 8MP MIPI CSI camera module |
| NeoEdge NG4500 edge AI box | You need an assembled system rather than a bare carrier-board build. | NG4500 Jetson Orin Nano/NX AI box |
What’s in the Box
- 1 x NeoEdge NG4500-CB01 carrier board
Customer-Provided or Sold Separately
- Compatible Jetson Orin Nano or Orin NX module
- Heat sink, fan, thermal interface material and mounting hardware
- M.2 2280 NVMe SSD
- Regulated DC power supply and regional AC power cord
- Enclosure, standoffs, mounting hardware and interface cables
- Wi-Fi/Bluetooth or 4G/5G module, antennas, SIM card and data plan
- CSI or USB camera and the correct ribbon or data cable
- RTC backup battery and project-specific I/O accessories
Specifications
| Item | Specification |
|---|---|
| Product type | Jetson Orin carrier board / development board |
| Board model | NG4500-CB01 |
| Compatible modules | Jetson Orin Nano 4GB/8GB; Jetson Orin NX 8GB/16GB |
| Module connector | 260-pin SO-DIMM |
| Compute and memory | Determined by the installed Jetson module |
| Ethernet | 2 x RJ45, 100/1000 Mbps |
| USB | 4 x USB 3.1 Type-A; 1 x USB 3.2 Type-C |
| Display | 1 x HDMI; published hardware guide lists HDMI 1.4 with Orin Nano and HDMI 2.1 with Orin NX |
| Industrial I/O | 4 x isolated DI, 4 x isolated DO, 1 x RS232, 1 x RS485, 1 x CAN, 5 V output |
| Primary storage expansion | M.2 Key M 2280, 4-lane PCIe path |
| Secondary storage expansion | M.2 Key M 2280, 1-lane PCIe path |
| Cellular expansion | M.2 Key B with Nano SIM slot for supported 4G/5G modules |
| Wi-Fi and Bluetooth expansion | M.2 Key E 2230 |
| Camera interfaces | 2 x 4-lane MIPI CSI |
| Additional expansion | 14-pin FFC with GPIO, I2C, SPI, UART and 3.3 V output |
| Audio | 3.5 mm audio input/output plus line, microphone and speaker headers |
| RTC | Supported through an onboard backup battery holder; battery sold separately |
| Power input | 12 to 36 V DC through the DC jack; power-mode setting depends on the Jetson module |
| Cooling | User-supplied, validated thermal solution required |
| Software | Ubuntu Linux with a compatible CamThink JetPack-based image |
| Published operating range | -25 C to 60 C for the NG4500 platform; validate the complete board, module, cooling and enclosure configuration |
Q: Does this product include a Jetson Orin module?
A: No. This SKU is the NG4500-CB01 carrier board only. Choose and purchase the Jetson Orin Nano or Orin NX module separately.
Q: Can the carrier board run without a fan?
A: The carrier board itself does not provide cooling for the Jetson module. Install a qualified heat sink and fan or another validated thermal solution before operation.
Q: Which slot should I use for the system SSD?
A: Use the 4-lane M.2 Key M 2280 slot for the primary NVMe system drive. The second Key M slot has a 1-lane PCIe path and is better suited to secondary storage.
Q: Can I add Wi-Fi, Bluetooth, 4G or 5G?
A: Yes. The board provides M.2 Key E for supported Wi-Fi/Bluetooth modules and M.2 Key B plus a Nano SIM slot for supported 4G/5G modules. Modules, antennas, SIM and service plan are not included.
Q: Is JetPack pre-installed?
A: The carrier board has no storage or Jetson module, so it cannot ship with an installed JetPack system. Flash a compatible CamThink image for the installed module by following the current system flashing guide.
